Launch Video GeoTagger #
Select this menu item to bring the GeoTagger tab to the front.
Photo Geotagging Options #
Watermark Captured Images with GPS Data #
When this option is checked, a still image snapped from a video will be watermarked with latitude, longitude, date, and time the video was recorded.
Geotag Single Photo #
Select this menu item to geotag a single photo.
Geotag Photos in Batch #
Select this menu item to geotag multiple photos based on photo and GPS coordinate time stamps.
Geotag Photos Using geoDVR CSV Log #
In certain situations, the geoDVR CSV log can be used to geotag photos that were captured but not geotagged during the mission. See the Geotag Photos Using the geoDVR CSV Log article for how to run the tool.
Enhance DJI Drone Metadata for Pix4D #
Select this menu item to generate a CSV file that can be used in Pix4D for faster model processing. This CSV file contains the vital omega, phi and kappa degrees data columns.
Parse DJI Log File #
Select this menu item to decrypt and parse a DJI Flight Record Log .TXT file into a format that can be used to geotag video from the UAV flight.
IMPORTANT: For newer drones and apps, DJI has changed the format of their encrypted Flight Record Log .TXT files and this is affecting our parser. Until we get our DJI parser updated, we recommend uploading the Flight Record Log .TXT files to AirData UAV (https://airdata.com/). AirData currently lets you convert the newer encrypted Flight Record Log .TXT file to a CSV file and our software does currently support the downloaded CSV from AirData. You can then use the converted CSV file from AirData instead of the encrypted .TXT file to access the extra metadata needed for geotagging in Remote GeoSystems software.
Extract Embedded GPS Data from Video #
DJI Video with Closed Captioning #
Select this menu option to extract the GPS data from the closed captioning of a DJI video file and create a new .GPX file to use for georeferencing the video file.
MISB FMV/STANAG 4609 Spec Video Video #
Select this menu item to extract the GPS data from the embedded KLV data in a MISB FMV/STANAG 4609-spec video file and create a new .GPX file to use for georeferencing the video file.
GoPro Video #
Select this menu item to extract the GPS data from the embedded data in a supported GoPro action camera video file and create a new .GPX file to use for georeferencing the video file.
